Lockey TB100 Turtle Back Hydraulic Gate Closer - TB100

Lockey TB100 Turtle Back Hydraulic Gate Closer

The Lockey TB100 Turtle Back Hydraulic Gate Closer features a top-of-the-line design with improved seals and a higher-performing cylinder for a superior product. They are designed to close small and large gates up to 125lbs gently. Pushes gate closed. Adjustable closing speed.

Features:

• Can be installed on top, bottom, or middle of the gate
• Recommended for pool, garden, and barrier gates
• Can be used on lightweight (non fire-rated) doors
• Works best on gates with in-line/flush hinges
• To retain product warranty & restrict gate opening angle, user must install a gate stop
• The LockeyUSA Turtle Back TB100 Hydraulic Gate closer must mount on the hinge side/pull side of the gate to push the gate closed. The TB100 works best if the gate has in-line/flush hinges flush with the gate post with 1" or less gap.

Dimensions & Specifications:

• Dimensions: 7 1/2" L x 13" W x 2 1/2" D
• Mounting Bracket Dimensions: 3 1/4" x 1 3/4"
• Max. Gate Weight: 125 lbs.
• Max. Gate Width: 54"
• Max. Opening Angle: 90 degrees
• Min. Operating Temperature: 10 degrees
• Max. Operating Temperature: 110 degrees
• Type of Gate Material: Vinyl, Wood, Steel, Chain Link
• Closing/Latching Method: Hydraulic
• Material: Steel
• Finish: Powder-Coated
• Color: Black
• Hinge Arrangements: In-line/flush hinges
• Opening Pressure: Variable, depending on gate size

General Warranty Policy

• LockeyUSA may request additional information to process warranty claims effectively.
• If the product is covered by warranty, it will be repaired or replaced at LockeyUSA's discretion.
• Return shipping within the United States is covered by LockeyUSA.
• International customers are responsible for all shipping costs, duties, and applicable fees.
• All warranty claims must include a completed LockeyUSA Warranty Claim Form and valid proof of purchase.
• Warranties only apply to products manufactured after December 31, 1999.

Lockey Hydraulic Gate Closers

• Warranty: One-Year Warranty
• Applies to: models TB100, TB175, TB200, TB250+, TB400, TB450+, TB600, TB650+
• Covers: Manufacturer defects in hydraulic operation.
• Does Not Cover: Vandalism, incorrect installation, and usage outside the recommended temperature range (15 degrees F to 100 degrees F).
• Important: Installation must limit gate opening to 90 degrees or less using gate stops. Units installed on spring-tensioned gates are not covered.
